SHEEP AND GOAT EQUIPMENT

PANELS WITH PINS

Different models

Rack with drinker protection (with pin)

SPECIFICATIONS
Ref Name Packaging Measurement A
• Manufactured using ø 27 and ø 20 tube Ultra panel, drinker
• Height 1m00 (7 tubes) 230 OV2125 cut-out, length 1.50 m 10 1560
• Stands with domed washers 1000 mm
• Domed vertical tube caps OV2126 Individual pin 25 1000
• Delivered with 1 pin 350 mm
• Panel reinforcement bar
4 lamb passage rack (with pin)

SPECIFICATIONS 2000 mm Ref Name Packaging

• Manufactured using 30x30 square tube OV2111 4 lamb passage panels 2m00 10
• Height 0m90, length 2m00 OV2126 Individual pin 25
• Panel composed of a fixed frame and a sliding 460 mm
frame. 900 mm
• 4 lamb passages adjustable from 0 to 157mm
• Shipped with pin 0 to 157 mm
• Shipped assembled
Sheet metal panels (with pin)

Ref Name Packaging Measurement A
SPECIFICATIONS
OV2024 Sheet metal panel 1 m 25 1000
• Manufactured using size 30 square tube
• Height 0.90 m 900 mm OV2025 Sheet metal panel 2 m 25 2000
• Delivered with 1 pin OV2026 Sheet metal panel 3 m 25 3000
• 670 mm high sheet metal on the
lower part with a protection tube Measurement A in mm OV2126 Individual pin 25 1000

Alpe panels Ref Name Packaging Measurement A
(with pin) OV2093 Alpe panel 1m00 25 1040

OV2095 Alpe panel 1m50 25 1590
SPECIFICATIONS
• Manufactured using tube 30x30 1000 mm OV2096 Alpe panel 2m00 25 2090
and Ø20 tube OV2098 Alpe panel 2m50 25 2570
• 7 tube bars
• Height 1m00 OV2099 Alpe panel 3m00 25 3070
• Shipped with pin Measurement A in mm OV2126 Individual pin 25 1000

Extendible barred sheep panels (with pin)

Ref Name Packag- Measurement Measurement
SPECIFICATIONS ing A minimum A maximum
860211 Extendible barred sheep panel 1/2m 25 1080 1975
• Manufactured using Ø20 tube
for the front part and Ø27 860212 Extendible barred sheep panel 2/3m 25 1630 3075
for the back 1000 mm 860213 Extendible barred sheep panel 3/4m 25 2630 4075
• Shipped with pin 860214 Extendible barred sheep panel 4/5m 25 3630 5075
860215 Extendible barred sheep panel 5/6m 25 4630 6075 SHEEP & GOATS
Measurement A in mm OV2126 Individual pin 25 - 1000
